Pressure range

0-30 tons

0-40 tons

0-60 tons

Pressure display accuracy

0.01 tons

Process Control

The program control reaches up to 18 steps

Curved graph pattern

It can display the operation curve graph for each time and supports downloading Excel files via USB drive

Speed Regulation

The boosting speed can be adjusted

Remote Control

A computer needs to be selected, lt can be used for data analysis,comparison,modification,export and other functions

Liquid Crystal Display (LCD)

7-inch (IPS high-definition) touch screen

Metal key/button

Silver-plated contacts, with a service life of over 100,000 cycles

Mold size

ф40mm/ф32mm(1 set of built-in molds)

Types of molds

Boric acid/Steel ring/Plastic ring /Aluminum ring

Mold material

Stainless steel 440C tool steel

Demolding method

The cantilever structure of the upper plate enables more convenient automatic demolding operation

Pressure safety

The device is equipped with automatic pressure overload protection

Limit Switch

The oil cylinder automatically releases pressure when it reaches the limit height

Equipment power supply

500W (220V/110V customizable)

Product Dimensions/Net

250x390x460mm/120kg

280x460x550mm/150 kg

300x520x580mm/180kg

Packaging Dimensions/ Gross

605x407x697mm/156kg

700x550x820mm/186 kg

700x550x820 mm/216 kg
