Internal Dimension
WxHxD (mm)

 400x500x400

 500x600x500

 600x750x500

 600x850x800

 1000x1000x800

 1000x1000x1000

 Internal Dimension WxHxD (mm)

 950x1650x950

 1050x1750x1050

 1200x1900x1150

 1200x1950x1350

 1600x2000x1450

 1600x2100x1450

 TemperatureRange

 Low Temperature(A:25°C  B:0°C  C:-20°C  D:-40°C  E:-60°C  F:-70°C)
 High Temperature 150°C

 HumidityRange

 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is a special optional condition, need Dehumidifier)

 Analytic Accuracy/
Distribution uniformity of
temperature and humidity

 0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H.

 Control Accuracy of
Temperature and Humidity

 ±0.5°C; ±2.5% R.H.

Cooling System

Wind cooling or water cooling/single segment compressor(-40°C, double segment compressor -70°C)

 Temperature Rising/Falling
Speed Rate

 Temperature rising approx.  0.1~3.0°C/min
temperature falling approx.  0.1~1.5°C/min;
( The Falling Speed Rate Min.1.5°Cper minute is a special optional condition)

 Power

 AC220V  1ph 3 lines, 50/60HZ ,  AC380V   3ph  5 lines , 50/60HZ

 Approx. Weight (Kg)

 150

 180

 250

 320

 400

 450
