Heating Temperature

Heating Power

RT-300°C/1.6KW
RT-500°C/2KW
RT-800°C/4.5KW

RT-300°C/2.2KW
RT-500°C/3.4KW
RT-800°C/6KW

RT-300°C/2.3KW
RT-500°C/4.5KW

RT-300°C/4KW
RT-500°C/6KW

Pressure Range

0.01-5.0 T

0.01-25.0 T

0.01-30.0 T

0.01-50 T

Pressure Accuracy

0.01 T

Vacuum Degree

-0.1 Mpa

Display Screen

7- inches Touch Screen

Metal key/button

Silver-plated contacts, with a service life of over 100,000 cycles

Curved graph pattern

It can display the operation curve graph for each time and supports downloading Excel files via USB drive.

Process Control

Up to 18 program controls, including pressure, temperature, and water cooling, can all be controlled independently.

Vacuum Control

Support manual activation of the vacuum pump and intake valve. In multi-stage programs  the vacuum degree of the vacuum chamber can also be automatically controlled.

Water cooling for cooling

Support manual activation of water cooling for cooling, and automatic rapid cooling can also be achieved in multiple program segments.

Speed Regulation

The boosting speed can be adjusted, and the heating speed can also be regulated.

Remote Control

A computer needs to be selected and equipped. It can perform functions such as data analysis, comparison, modification, and export.

Plate Size
(M X N)

120x120 mm

200 x200 mm

300 x 300 mm

400 x 400 mm

Working Space

130 x 55 mm

210 x 65 mm

320 x 70 mm

420 x 90 mm

Hatch Size
(M X N)

300 x200mm

380 x 200mm

380x200mm(

480 x200mm

Power Supply Power

220V / 110V Customizable

Vacuum Pump Size/Weight

490 x230 x340 mm /14 kg

Product Dimensions/Weight

480 x560 x750 mm/
280 kg

580x660x1200mm/
480 kg

580x680x1200 mm/
580 kg

680x 760x 1200 mm/
1130kg

Package Dimensions/Gross Weight

900x800x1400 mm /350 kg

900 x800x1400 mm /550 kg

900x800x1400 mm/650 kg

900 x 800 x 1400mm/
1200kg
